Model

M204

Processor

Support Skylake 3855U,3955U,I3-6100U,I5-6200U,I7-6500U,etc

Memory

1xNB DDR4 Memory channel,support Max 16GB RAM.

Ethernet

Realtek 8111F 1000Mbps LAN, optional 2xLAN.

Audio

Realtek ALC662 HD Audio,support Line-out,Mic-in,SPDIF,Speaker.

CPU Graphics

Intel HD Graphics 510/520/610/620 on CPU,support 4K(UHD),1080P(2K,FHD),H264,3D play.

Display

VGA,HDMI,EDP,support synchronously,asynchronously dual,three display.

Hard Disk

1xSATA3.0 , 1xM.2(2242/2280)

Power Supply

DC 12V~19V, recommend 12V/5A(Or more than 5A).

DC port:5.5x2.5MM

CPU_FAN

Thin Silent Cool FAN

Form Factor

Nano-ITX ,120 x120x36mm(L x W x H)

I/O Port

DC-in,HDMI,VGA,4xUSB,LAN,Line-out,Mic-in,power button.

Build-in Pin

EDP,VGA,4xUSB,2xCOM(Optional RS232/RS422/RS485),GPIO,FAN,SIM Card slot,SPDIF,Speaker,Audio.

Expansion

1xMini-PCIE slot,support Wifi,Bluetooth,4G/3G,MSATA .

Temperature

-20℃~60℃(Working)   -20℃~70℃（Storage)

Working Humidity

5-95% relative humidity,non-condensing.

Operating System

Support Windows 7 , Windows 8 , Windows 10 , Linux .

Fitted Case

N67

Architecture

X86 architecture

Watch dog

Watch dog programming, support hardware reset function (256 levels, 0~255 seconds).

BIOS

AMI BIOS;Support read only,power on,timing switch,remote switch,intelligently identify devices.

Purchasing Information:

MOQ

1 piece

Net Weight

0.4KG/piece

Package Size

20*20*7CM for 1 piece

Payment Ways

T/T,Western Union,Alipay,Wechat Pay,Paypal,Alibaba Trade Assurance,RMB Cash,etc.

Delivery Time

1~3 working days

Shipping Ways

DHL,Fedex,UPS,TNT,etc.

Warranty

3 years for motherboard;1 year for CPU,RAM,SSD,HDD,WIFI,4G,etc.

OEM/ODM

Welcome

Certificates

CE , CCC , ISO , MSDS , UN38.3 , UN3091 , POA
