Specifications |
| |
name | 10.1 inch Industrial Tablet PC | |
processor | Optional Intel® Celeron ® J1900 or the first 4 / 7 / 8 / 1 1 Generation Core i3 / i5 / i7 CPU | |
system memory | One SODIMM slot, maximum support 16GB | |
network | 2 x GbE RJ45 2 | |
I / O interface | 3 x USB2.0, 1 x USB3.0 2 x DB-9 COM1&COM2,RS-232/485 2 x 3-wire COM3&COM4 RS-232/485 Phoenix 2 x 3-wire COM5&COM6 RS-232 Phoenix 1 x Audio Line-out 2 x 8Ω 1W output (optional) 1 x phoenix remote switch can be connected to the optional port 1 x HDMI 1 x 12bit GPIO (optional) | |
storage | 1 x mSATA 1 x SATA ( 2.5” SATA ) | |
expansion slot | Mini-PCIe x1 half card，support WIFI blue bluetooth | |
watchdog timer | 1~255 seconds programmable setting | |
support system structure | Windows® 7 /8/10, WES 7, LINUX | |
|
| |
material | aluminum | |
installation method | VESA 75/ panel mount | |
size | 283.2 x 186.9 x 50.5mm | |
weight use environment | 2.0KG ( J1900 ) | |
|
| |
Operating temperature | 0°C ~ 60°C | |
storage temperature | - 30°C ~ 70°C | |
storage humidity power supply | 10~90% @30°C, non-condensing | |
|
| |
power input display screen | DC 9 ~ 36V 2-pin Phoenix terminal | |
|
| |
LCD type | 10.1" TFT-LCD | |
resolution | 1280 x 800 | |
maximum color | 16.2M | |
brightness | 400 cd/m² | |
Viewing angle ( CR>=10 ) | ~ 85° (H), -85~85° (V) | |
backlight | led | |
Backlight life ( hours ) touch screen | 30,000 | |
|
| |
type | 5 -wire resistive | 10 point capacitive screen |
Transmittance | 78% | more than 85% |
service life | 10 million clicks with 250 grams of strength | Hardness 7H |
10.1 inch industrial panel pc,industrial all-in-one pc touch screen
