Specifications

Display interface

VGA,HDMI

Shell Material

Aluminum, SGCC

Size

397.3 x 255.3 x 41.3 mm

Weight

2.43 KG

Power input

12V /3A

Support System

Windows® 7/8/10, WES 7, Linux

OSD menu

Adjustable screen brightness, contrast, support one-key adjustment to the best state

Installation method

Panel Mount, Wall Mount, Desktop Mount, VESA75 Cantilever Mount

Display

LCD Type

TFT-LCD

Resolution

1920 x 1080

Max Color

16.2M

Brightness

300 cd/m²

Perspective(CR>=10)

-85~85° (H), -85~85° (V)

Backlight

LED

Backlight Lifetime (hours)

30,000

Contrast

800:1

Touch screen

Type

Five-wire resistive

10 point capacitive screen

Interface Type

USB2.0

USB2.0

Transmittance

85%

greater than85%

Lifetime

250g force 10 million clicks

Hardness 7H

Use environment

Operating temperature

0℃ ~60℃

Storage temperature

-20°C ~ 70°C

Storage humidity

10~90% @30°C, no condensation

Protection Level

Front panel IP65

Vibration resistance

5~500 Hz, 1Grms (operating,ramdom)
