Specifications

Display interface

VGA,HDMI

Shell Material

Aluminum, SGCC

Size

276.1 x 285.3 x 43.3 mm

Weight

2.1 KG

Power input

12V /3A

Support System

Windows® 7/8/10, WES 7, Linux

OSD menu

Adjustable screen brightness, contrast, support one-key adjustment to the best state

Installation method

Panel Mount, Wall Mount, Desktop Mount, VESA75 Cantilever Mount

Display

LCD Type

TFT-LCD

Resolution

1024 x 768

Max Color

16.7M

Brightness

500 cd/m²

Perspective(CR>=10)

-89~89° (H), -89~89° (V)

Backlight

LED

Backlight Lifetime (hours)

30,000

Contrast

1000:1

Touch screen

Type

Five-wire resistive

10 point capacitive screen

Interface Type

USB2.0

USB2.0

Transmittance

85%

greater than85%

Lifetime

250g force 10 million clicks

Hardness 7H

Use environment

Operating temperature

-20℃ ~ 70℃

Storage temperature

-20°C ~ 70°C

Storage humidity

10~90% @30°C, no condensation

Protection Level

Front panel IP65

Vibration resistance

5~500 Hz, 1Grms (operating,ramdom)
