| ARK-6322-Q0A2E | ||
| Processor | CPU | Intel Celeron Processor J1900 Quad Core |
| Processor | Core Number | 4 |
| Processor | L2 Cache | 2 MB |
| Processor | Max Speed | 2.0 GHz, Turbo Boost up to 2.41GHz |
| Processor | BIOS | AMI 16 Mbit SPI (Default BIOS is supported for 64-bit OS installation, BIOS for 32-bit OS is supported by project) |
| Memory | Technology | Dual channel DDR3L 1333MHz SDRAM |
| Memory | Max. Capacity | 8 GB |
| Memory | Socket | 2 x 204-pin SO-DIMM |
| Memory | ECC Support | No |
| Graphics | Controller | Intel Gen 7 Graphics Engines and media encode/decode engine; GPU Frequency: 688 MHz |
| Graphics | VRAM | Shared system memory up to 224 MB SDRAM |
| Graphics | Display port | 1 |
| Graphics | VGA | 1 |
| Graphics | Dual Display | VGA+DP |
| Audio | Main System | Realtek ALC892, High Definition Audio, Line-out, Mic-in |
| Ethernet | LAN1 | 10/100/1000 Mbps RTL8111E GbE |
| Ethernet | LAN2 | 10/100/1000 Mbps RTL8111E GbE |
| I/O Interface | Serial Port | 5 x RS-232, 1 x RS232/422/485 |
| I/O Interface | Serial | 6 |
| I/O Interface | USB Interface | 1 x USB 3.0 port and 7 x USB 2.0 ports |
| I/O Interface | USB2.0 | 7 |
| I/O Interface | USB3.0 | 1 |
| I/O Interface | GPIO | 8-bit |
| Expansion | Mini PCI Express | 2 |
| Expansion | Mini PCIe #1 | 1 x Full-size Mini PCIe, supports mSATA module and WWAN module; |
| Expansion | Mini PCIe #2 | 1 x Half-size Mini PCIe, supports WLAN module |
| Others | Watchdog timer | 255 levels timer interval, setup by software |
| Storage | mSATA | 1 x mSATA share with mini-PCIe slot |
| Storage | 2.5" HDD/SSD | 1 x SATA HDD Bay for 2.5" or 3.5" device with maximum height 26.1mm |
| Software Support | Microsoft Windows | Windows 10, Windows 8 , Windows 7, WES8, WES7 |
| Software Support | Linux | Support by project |
| Power | Power Type | ATX |
| Power | Input Voltage | 12 VDC |
| Power | Power Adaptor | AC to DC, DC12V/5A, 60 W (Optional) |
| Power | Consumption | Typical 15.7 W, Max. 24.7 W |
| Power Consumption | Typical | 15.7W |
| Power Consumption | Max. | 24.7W |
| Mechanical | Construction | Aluminum housing |
| Mechanical | Mounting | Wall mounting kit (optional), VESA mounting kit (optional) |
| Mechanical | Dimensions | 200 x 64 x 200 mm |
| Mechanical | Weight | 2.0 kg |
| Environment | Operational Temperature | With extended temperature peripherals/SSD: 0 ~ 50° C (32 ~ 122° F) with 0.7 m/s air flow, With 3.5-inch hard disk 0 ~ 40° C (32 ~ 104° F) with 0.7 m/s air flow, With 2.5-inch hard disk 0 ~ 45° C (32 ~ 112° F) with 0.7 m/s air flow |
| Environment | Storage Temperature | -40 ~ 85° C (-40 ~ 185° F) |
| Environment | Relative Humidity | 95% @ 40° C (non-condensing) |
| Environment | Vibration During Operation | With HDD: 0.5 Grms, IEC 60068-2-64, random, 5~500Hz, 3 axes, 1hr/axis |
| Environment | Shock During Operation | With HDD: 10 G, IEC 60068-2-27, half sine, 11 ms duration |
| Certification | EMC | CE/FCC Class A, CCC, BSMI |
| Certification | Safety Certifications | CB, UL, CCC, BSMI |
Advantech ARK-6322 Intel Celeron Quad Core J1900 SoC with 6 COM and 8 USB Fanless Box PC
