| AMAX-5082-A | ||
| Counter/Encoder Input | Encoder Type | Absolute Encoder |
| Counter/Encoder Input | Channels | 1 |
| Counter/Encoder Input | Counting Range | 32-bit |
| Counter/Encoder Input | Max. Input Frequency | 2 MHz |
| Counter/Encoder Input | Mode | SSI (Binary, Gray) |
| General | Connectors | 1 x 4-pin plug-in screw terminal, 1 x 8-pin plug-in screw terminal |
| General | Protocol | EtherCAT |
| EtherCAT | Cycle Time | 100 μs |
| Hardware | Certification | CE, FCC class A |
| Hardware | LED Indicators | PWR, R/E, CLK, DATA, DO0, DO1, LATCH |
| Hardware | Power Consumption | 3 W @ 24 VDC |
| Environment | Isolation Voltage | 2,000 VDC |
| Environment | Operating Temperature | -25~45 °C (-13~113 °F) |
| Environment | Relative Humidity | 95% RH (non-condensing) |
| Environment | Storage Temperature | -40~85 °C (-40~185 °F) |
| Environment | Storage Humidity | 95% RH (non-condensing) |
| Mechanical | Enclosure | PC |
| Mechanical | Mounting | DIN-rail |
| Mechanical | Weight (Net) | 92 g |
| Mechanical | Dimension (W x H x D) | 14.6 x 105.9 x 94.7 mm |
Advantech AMAX-5082 1-ch SSI Absolute Encoder EtherCAT Slice IO Module
