Advantech ADAM-5000/485 4-slot Distributed DA&C System for RS-485

RS-485 communication for easy installation and networking

4 slots for up to 64 points data monitoring card control in one module

Supports ADAM ASCII protocol or Modbus®/RTU protocol

Supports Modbus/RTU protocol with user-defined Modbus address

Extensive software support, includes windows DLL drivers, OCX drivers, OPC server and popular HMI/SCADA software drivers

Seamlessly integrated with easy-to-use ADAMView data acquisition software

		ADAM-5000/485-AE
Environment	Operating Temperature	-10~70 °C (14~158 °F)
Environment	Storage Temperature	-25~85 °C (-13~185 °F)
General	Connectors	1 x DB9-M/DB9-F/screw terminal for RS-485 (communication), 1 x DB9-F for RS-232 (configuration), 1 x screw terminal for power input
General	Humidity (Operating)	5~95% RH (non-condensing)
General	Humidity (Storage)	5~95% RH (non-condensing)
Hardware	Certification	CE, FCC class A
Hardware	CPU	16-bit 80188 microprocessor
Hardware	Expansion	4 x I/O Slot
Hardware	I/O	1 x RS-232, 1 x RS-485
Hardware	LED Indicators	Power, RUN, Communications
Hardware	Power Input	10~30 VDC
Hardware	Watchdog Timer	1.6 s
Mechanical	Dimension (W x H x D)	231 x 110 x 75 mm
Mechanical	Enclosure	PC + ABS
Mechanical	Mounting	Wall, DIN-rail
