| PCIE-1841-A | PCIE-1841L-A | ||
| Analog Input | Channels | 16 | 8 |
| Analog Input | Input Range | ±20 V, ±12.5 V, ±10 V, ±5 V, ±20 mA | ±20 V, ±12.5 V, ±10 V, ±5 V, ±20 mA |
| Analog Input | Resolution(Bits) | 16-bit | 16-bit |
| Analog Input | Sampling Rates(S/s) | 1 MS/s (per channel) | 1 MS/s (per channel) |
| Digital Input | Channels | 1 (TTL) | 1 (TTL) |
| Digital Output | Channels | 2 (TTL) | 2 (TTL) |
| General | Programming Language | C#, C++, LabVIEW, VB.Net, BCB, MFC, VB6, Delphi, Java, Matlab, Qt | C#, C++, LabVIEW, VB.Net, BCB, MFC, VB6, Delphi, Java, Matlab, Qt |
| Environment | Operating Temperature | 0~60 °C (32~140 °F) | 0~60 °C (32~140 °F) |
Advantech PCIE-1841 16/8-ch, 18-bit, 1MS/s/ch Simultaneous Analog Input PCI Express DAQ Card
