Advantech USB-5820 4-ch, 16-bit, 200 kS/s Isolated Analog Output USB 3.0 I/O Module - industrial computer

Advantech USB-5820 4-ch, 16-bit, 200 kS/s Isolated Analog Output USB 3.0 I/O Module

USB 3.0 SuperSpeed

Daisy chainable by built-in USB hub

4 x 16-bit analog output channels with 2,500 V DC isolation

Multiple voltage and current output ranges

Removable European-type connector

Supported operating systems: Windows XP/7/8/10

Inquiry

Description

		USB-5820-AE
Analog Output	Channels	4
Analog Output	Isolation Protection	2,500 VDC
Analog Output	Output Ranges	0~5 V, 0~10 V, ±5 V, ±10 V, 0~20 mA, 4~20 mA
Analog Output	Resolution	16-bit
Analog Output	Update Rate(S/s)	200 KS/s
General	Programming Language	C#, C++, LabVIEW, VB.Net, BCB, MFC, VB6, Delphi, Java, Matlab, Qt
