| TPC-307W-PE20A | ||
| Hardware | BIOS | AMI UEFI |
| Hardware | Certification | CB, UL, CE, FCC Class A, CCC, BSMI |
| LCD Display | Display Size | 7" |
| LCD Display | Max. Resolution | 1024 x 600 |
| LCD Display | Luminance (cd/m2) | 500 |
| LCD Display | Viewing Angle (H/V°) | 160/140 |
| LCD Display | Backlight Life (hrs) | 50,000 |
| Touchscreen | Touch Type | PCAP |
| Environment | Ingress Protection | Front Panel IP66 |
| Hardware | CPU | Intel® Atom™ 1.33 GHz |
| Hardware | Memory | 1 x DDR4 SO-DIMM Slot |
| I/O Interface | Expansion | 1 x M.2 B key, 1 x M.2 E key |
| Hardware | Storage | 1 x M.2 B key |
| I/O Interface | USB Ports | 2 x USB 3.0, 2 x USB 2.0 |
| Hardware | LAN | 2 x 10/100/1000 Mbps |
| Environment | Storage Temperature | -30~70 °C (-22~158 °F) |
| Environment | Operating Temperature | -20~60 °C (-4~140 °F) |
| Environment | Vibration Protection | 1 Grms, random |
| General | Humidity (Operating) | 10~95% RH (non-condensing) |
| Hardware | OS Support | Microsoft® Windows 10 LTSC, Linux, Android |
| Hardware | Watchdog Timer | 15~255 s |
| I/O Interface | Audio | Line-Out |
| I/O Interface | Serial Ports | 1 x RS-232, 1 x RS-232/422/485 |
| Hardware | Power Consumption | 19.2 W @ 24 VDC |
| Mechanical | Enclosure | Die-cast aluminum alloy |
| Mechanical | Mounting | Stand, Wall, VESA, Panel |
| Mechanical | Weight (Net) | 1.5 kg (3.30 lb) |
Advantech TPC-307W 7" WSVGA TFT LED LCD Thin-Client Terminal with Intel® Elkhart LakeR
