| SPC-221-633AE | ||
| Environment | Ingress Protection | All-around IP66 |
| Environment | Operating Temperature | 0~55 °C (32~131 °F) |
| Environment | Relative Humidity | 95% RH (non-condensing) |
| Environment | Storage Temperature | -20~60 °C (-4~140 °F) |
| Environment | Vibration Protection | 1 Grms, random |
| General | Humidity (Operating) | 10~95% RH (non-condensing) |
| General | Humidity (Storage) | 10~95% RH (non-condensing) |
| General | Rated Voltage | 24 VDC |
| Hardware | BIOS | AMI UEFI |
| Hardware | Certification | CB, UL, CE, FCC Class A, CCC, BSMI |
| Hardware | CPU | Intel® CoreTM i3-6100U 2.3GHz Skylake Dual Core, 3MB L2 |
| Hardware | Hardware Security | Optional |
| Hardware | I/O | 1 x RS-232, 1 x USB 2.0 |
| Hardware | LAN | 2 x 10/100/1000 Mbps |
| Hardware | Memory | 2 x SO-DIMM with 8GB DDR3L |
| Hardware | OS Support | Microsoft® Windows 10 LTSC |
| Hardware | Power Consumption | 35 W @ 24 VDC |
| Hardware | Power Input | 24 VDC ±20% |
| Hardware | Power Requirement | 24 VDC ±20% |
| I/O Interface | Expansion | Optional |
| I/O Interface | LAN Ports | 2 x 10/100/1000 Mbps |
| I/O Interface | Power Connector | 1 x M-12 A-coded 5 pin male |
| I/O Interface | Serial Ports | 1 x RS-232 |
| I/O Interface | USB Ports | 1 x USB 2.0 |
| LCD Display | Backlight Life (hrs) | 50,000 |
| LCD Display | Display Size | 21.5" |
| LCD Display | Luminance (cd/m2) | 300 |
| LCD Display | Max. Resolution | 1920 x 1080 |
| LCD Display | Viewing Angle (H/V°) | 178/178 |
| Mechanical | Dimension (W x H x D) | 558.4 x 349.8 x 65 mm |
| Mechanical | Enclosure | Die-cast aluminum alloy |
| Mechanical | Form Factor | Passive Cooling |
| Mechanical | Mounting | VESA |
| Mechanical | Weight (Net) | 9 kg (19.8 lb) |
| Power Requirements | Input Voltage | 19~29 VDC |
| Touchscreen | Touch Type | PCAP |
| Hardware | Storage | 2.5" SATA HDD bracket x 1 |
Advantech SPC-221 21.5" Full HD LED LCD Stationary Multi-Touch Panel Computer
