Advantech TPC-318WH Computer with 8th Gen. Intel® Core™ i5 Processor, built-in 8G DDR4 RAM and UL Class 1 Division 2

Industrial-grade 18.5" WXGA TFT LCD with 50K lifetime and LED backlight

8th Gen. Intel® Core™ i5-8365UE quad-core processor with built-in 8 GB DDR4 SO-DIMM

Dual channel memory slots support up to 64G in total

Compact, fanless embedded system with aluminum alloy front bezel and chassis grounding protection

True-flat touchscreen with PCAP touch control and IP66-rated front panel

Support expansion via Full-size Mini PCIe and two M.2 slots (NVMe, 5G)

Support TPM2.0 hardware security

		TPC-318WH-P853A
LCD Display	Display Size	18.5"
Power Supply	Input Voltage	12~24 VDC
LCD Display	Luminance (cd/m2)	450
Touchscreen	Touch Type	10-point multi-touch projected capacitive
LCD Display	Max. Resolution	1366 x 768
Hardware	CPU	8th Gen. Intel® Core™ i5-8365UE 1.60GHz Quad-Core
Hardware	Memory	1 x SO-DIMM Memory with 8 GB DDR4 3200 MHz
I/O Interface	LAN Ports	2 x 10/100/1000 Mbps
Hardware	Storage	1 x SATA M.2 SSD slot (2280 M-Key);1 x 2.5" SSD/HDD Bay, 1 x mSATA, 1 x M.2 B key
I/O Interface	USB Ports	4 x USB 3.2
USB Vision	Connector	1 x USB 2.0 Type A
I/O Interface	Serial Ports	2 x RS 232/422/485
I/O Interface	Displays	1 x DP
I/O Interface	Audio	Line-Out, Mic-In
Expansion Function	Interface	1 x Full-size mini PCIe
Mechanical	Mounting	Panel, Wall, Stand, VESA
