Advantech FPM-215W 15.6" WXGA Industrial Monitor with P-CAP Touch Control, Direct HDMI Port

15.6" WXGA TFT LED LCD with true-flat touchscreen

16:9 wide screen aspect ratio, increases viewing area by 40%

Supports 10-point multi-touch control via USB interface in Windows 7/8/10 OS

Slim design enables easy installation

Supports various mount options: panel, wall, desktop, and VESA arm

Touchscreen with reliable glass surface and P-CAP touch control

Robust system with Die-casting aluminum chassis and IP66-rated aluminum alloy front bezel

Lockable I/O connectors

		FPM-215W-P4AE
Environment	Ingress Protection	Front Panel IP66
Environment	Operating Temperature	0~50 °C (32~122 °F)
Environment	Storage Humidity	10~95% RH (non-condensing)
Environment	Storage Temperature	-20~60 °C (-4~140 °F)
Environment	Vibration Protection	1 Grms, random
Hardware	Certification	CB, UL, CE, FCC Class A, CCC, BSMI
Hardware	OS Support	Microsoft® Windows Vista, Microsoft® Windows 7, Microsoft® Windows 8,Microsoft® Windows XP, Microsoft® Windows XPe, Microsoft® Windows CE, Linux,Microsoft® Windows 10 LTSB
Hardware	Power Input	12 VDC
Hardware	Video Port	HDMI
I/O Interface	Power Connector	1 x Lockable DC Jack
LCD Display	Backlight Life (hrs)	50,000
LCD Display	Display Size	15.6"
LCD Display	Luminance (cd/m2)	300
LCD Display	Max. Resolution	1366 x 768
LCD Display	Viewing Angle (H/V°)	160/160
Mechanical	Dimension (W x H x D)	419.7 x 269 x 56.2 mm
Mechanical	Enclosure	Die cast magnesium alloy, Die-casting aluminum
Mechanical	Mounting	Stand, Wall, VESA, Panel
Mechanical	Weight (Net)	4 kg (8.82 lb)
Touchscreen	Touch Type	PCAP
