Advantech FPM-815S 15" XGA Industrial Monitor with Resistive Touch Control, Direct VGA, DP Ports, and 304 Stainless Steel Front Bezel

15" XGA TFT LED LCD with 70K backlight lifetime

Robust design with 304 stainless steel front bezel and anti-rust coated SPCC rear cover

Wide operating temperature range (-20 ~ 60 °C/-4 ~ 140 °F)

Increased reliability with enhanced 5-wire resistive touch sensor

Anti-glare screen with tempered glass and IP66-certified front panel

Direct VGA & DP video input interface

OSD control pad with lockable function on rear panel

Supports panel, VESA, wall, desktop, and stand mounting

		FPM-815S-R6AE
Environment	Ingress Protection	Front Panel IP66
Environment	Operating Temperature	-20~60 °C (-4~140 °F)
Environment	Storage Humidity	10~90% RH (non-condensing)
Environment	Storage Temperature	-30~70 °C (-22~158 °F)
Environment	Vibration Protection	1 Grms, random
Hardware	Certification	CB, UL, CE, FCC Class A, CCC, BSMI
Hardware	OS Support	Microsoft® Windows Vista, Microsoft® Windows 7, Microsoft® Windows 8,Microsoft® Windows XP, Microsoft® Windows XPe, Microsoft® Windows CE, Linux,Microsoft® Windows 10 LTSB
Hardware	Power Input	24 VDC
Hardware	Video Port	VGA, DP
I/O Interface	Power Connector	1 x Phoenix Jack
LCD Display	Backlight Life (hrs)	70,000
LCD Display	Display Size	15"
LCD Display	Luminance (cd/m2)	500
LCD Display	Max. Resolution	1024 x 768
LCD Display	Viewing Angle (H/V°)	176/176
Mechanical	Dimension (W x H x D)	405.3 x 329.4 x 59.3 mm
Mechanical	Enclosure	304 stainless steel bezel, SPCC with anti-rust coating
Mechanical	Mounting	Stand, Wall, VESA, Panel
Mechanical	Weight (Net)	5.4 kg (11.90 lb)
Touchscreen	Touch Type	5-wire resistive
