Advantech EKI-2701MPI Hardened PoE injector, 1000Mbps, 90W

    Supports operating temperatures from -40 ~ 75°C

    Provides slim size and DIN-rail with IP40 metal mechanism

    Power input 55~57 VDC, Inject power up to 90W

    IEEE802.3af/at/bt compliant

    Supports 10/100/1000Base-T (X) for PoE OUT and Data IN

EKI-2701MPI-AE
Environment Operating Temperature -40 ~ 75°C (-40 ~ 167°F)
Mechanism Dimensions (W x H x D) 25 x 80 x 84 mm (0.98 x 3.15 x 3.31 in.)
Certification EMC CE, FCC
Certification EMI EN 55011/ EN 55022 Class A, EN 61000-6-4, FCC Part 15 Subpart B Class A
Certification EMS EN 61000-4-2 (Level 4), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 4), EN 61000-4-5 (Level 4), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 4)
Certification Ethernet Standard IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.3z, 802.3af, 802.3at, HDBaseT, 802.3bt
Certification Freefall IEC 60068-2-32
Certification Shock IEC 60068-2-27
Certification Vibration IEC 60068-2-6
Environment Storage Temperature -40 ~ 85°C (-40 ~ 185°F)
Ethernet Communication RJ-45 Transmission Distance 100 m
Mechanism Enclosure (Metal) Metal
Mechanism IP Rating IP40
Mechanism Mounting DIN-rail, Wall mount
Mechanism Weight 250 g
MTBF Method Telcordia(Relax), GB
PoE Information PoE Port Number 1
Power Power Connector Type 6-pin removable screw terminal (power & relay)
Power Power Consumption 92W
Power Power Operating Current 1.8A @ 53 VDC ; 1.68A @ 55 VDC
Warranty Warranty Period 2 years
Certification Safety UL 62368
