Advantech UTC-120G 21.5" All-in-One Touch Computer with Intel® Pentium® N4200 processor

    Slimmer and Lighter design

    Low power and fanless system design

    Built-in Intel® Pentium® N4200

    21.5" monitor with 16:9 widescreen display

    IP65-rated front panel for water and dust resistance

    Clean back cover design with 3 Way IO cable routing

    Supports both landscape and portrait screen orientations

    VESA 100 mm standard mounting holes for varied mounting demands

    Support DeviceOn/iService software for remote device management

UTC-120GP-WWW1E UTC-120GP-AWW1E UTC-120GP-WUS1E UTC-120GP-NUS1E UTC-120GP-WEU1E UTC-120GP-IOT2E
Color Color Silver Silver Silver Silver Silver Silver
Display Size 21.5" TFT LCD 21.5" TFT LCD 21.5" TFT LCD 21.5" TFT LCD 21.5" TFT LCD 21.5" TFT LCD
Display Max. Resolution FHD (1920 x 1080) FHD (1920 x 1080) FHD (1920 x 1080) FHD (1920 x 1080) FHD (1920 x 1080) FHD (1920 x 1080)
Display Brightness 250 cd/m² 250 cd/m² 250 cd/m² 250 cd/m² 250 cd/m² 250 cd/m²
Touch Screen Type Projected Capacitive Projected Capacitive Projected Capacitive Projected Capacitive Projected Capacitive Projected Capacitive
Processor System CPU Intel® Pentium® N4200 Intel® Pentium® N4200 Intel® Pentium® N4200 Intel® Pentium® N4200 Intel® Pentium® N4200 Intel® Pentium® N4200
Processor System RAM 4GB DDR3L 4GB DDR3L 4GB DDR3L 4GB DDR3L 4GB DDR3L 4GB DDR3L
Processor System Storage 128G SSD 128G SSD 128G SSD 128G SSD 128G SSD 128G SSD
Processor System OS Windows 10 IoT Enterprise 64bit Android 10.1 Windows 10 IoT Enterprise 64bit Win 10 IoT Enterprise 64bit / Android 10.1 / Linux Ubuntu 20.04 Windows 10 IoT Enterprise 64bit Windows 10 IoT Enterprise 64bit
I/O Interface Serial Port 2 x COM (RS-232) 2 x COM (RS-232) 2 x COM (RS-232) 2 x COM (RS-232) 2 x COM (RS-232) 1 x COM (RS-232)
I/O Interface USB Port 4 x USB 3.0 / 2 x USB 3.0 (optional) 4 x USB 3.0 / 2 x USB 3.0 (optional) 4 x USB 3.0 / 2 x USB 3.0 (optional) 4 x USB 3.0 / 2 x USB 3.0 (optional) 4 x USB 3.0 / 2 x USB 3.0 (optional) 2 x USB3.0, 2 x USB3.0 (optional)
I/O Interface Ethernet 2 x Gigabit Ethernet ports 2 x Gigabit Ethernet ports 2 x Gigabit Ethernet ports 2 x Gigabit Ethernet ports 2 x Gigabit Ethernet ports 2 x Gigabit Ethernet ports
I/O Interface Output 1 x HDMI 1.4 1 x HDMI 1.4 1 x HDMI 1.4 1 x HDMI 1.4 1 x HDMI 1.4 1 x HDMI 1.4
I/O Interface Audio 1 x Audio Phone Jack 1 x Audio Phone Jack 1 x Audio Phone Jack 1 x Audio Phone Jack 1 x Audio Phone Jack 1 x Audio Phone Jack
I/O Interface Speaker 2 x 2W Speaker 2 x 2W Speaker 2 x 2W Speaker 2 x 2W Speaker 2 x 2W Speaker 2 x 2W Speaker
I/O Interface Extendable Slot 1 x M.2 key2230, 1 x M.2 key2242 1 x M.2 key2230, 1 x M.2 key2242 1 x M.2 key2230, 1 x M.2 key2242 1 x M.2 key2230, 1 x M.2 key2242 1 x M.2 key2230, 1 x M.2 key2242 1 x M.2 key2230, 1 x M.2 key2242
Peripheral WLAN IEEE 802.11a/b/g/n/ac IEEE 802.11a/b/g/n/ac IEEE 802.11a/b/g/n/ac IEEE 802.11a/b/g/n/ac IEEE 802.11a/b/g/n/ac IEEE 802.11a/b/g/n/ac
Peripheral Bluetooth Bluetooth® v4.1 Bluetooth® v4.1 Bluetooth® v4.1 Bluetooth® v4.1 Bluetooth® v4.1 Bluetooth® v4.1
Environment Operating Temperature 0~40° C 0~40° C 0~40° C 0~40° C 0~40° C 0~40° C
Environment Operating Humidity 10 ~ 95% @ 40°C non-condensing 10 ~ 95% @ 40°C non-condensing 10 ~ 95% @ 40°C non-condensing 10 ~ 95% @ 40°C non-condensing 10 ~ 95% @ 40°C non-condensing 10 ~ 95% @ 40°C non-condensing
Environment Vibration 0.5G 0.5G 0.5G 0.5G 0.5G 0.5G
Environment Shock 10G peak acceleration (11 msec. duration) 10G peak acceleration (11 msec. duration) 10G peak acceleration (11 msec. duration) 10G peak acceleration (11 msec. duration) 10G peak acceleration (11 msec. duration) 10G peak acceleration (11 msec. duration)
Environment System Protection IP65 front panel IP65 front panel IP65 front panel IP65 front panel IP65 front panel IP65 front panel
Power Input Rating 12 V/7 A (84 W ITE Adapter) 12 V/7 A (84 W ITE Adapter) 12 V/7 A (84 W ITE Adapter) 12 V/7 A (84 W ITE Adapter) 12 V/7 A (84 W ITE Adapter) 12 V/7 A (84 W ITE Adapter)
