| UTC-124I1P-WWW1E | ||
| Color | Color | Silver |
| Display | Size | 23.8" TFT LCD |
| Display | Max. Resolution | FHD (1920 x 1080) |
| Display | Brightness | 350 cd/m² |
| Touch Screen | Type | Projected Capacitive |
| Processor System | CPU | Intel® Core™ i5-1145G7E |
| Processor System | RAM | 8G DDR4 |
| Processor System | Storage | 128GB SSD |
| Processor System | OS | Windows 10 IoT Enterprise 64bit |
| Processor System | TPM | TPM 2.0 |
| I/O Interface | Serial Port | 2 x COM (RS-232) |
| I/O Interface | USB Port | 3 x USB 3.2 Gen1 Type-A, 1 x USB 3.2 Gen 1 Type-C, 1 x DC-in USB Type-C |
| I/O Interface | Ethernet | 2 x Gigabit Ethernet ports |
| I/O Interface | Output | 1 x HDMI 1.4 |
| I/O Interface | Audio | 1 x Audio Phone Jack |
| I/O Interface | Speaker | 2 x 2W Speaker |
| I/O Interface | Extendable Slot | 1 x M.2 key2230, 1 x M.2 key2280 |
| Process System | Mounting | VESA 100 x 100 mm (Screw Size, M4, 7mm) |
| Process System | Dimension (WxHxD) | 587 x 356 x 42.5 |
| Process System | Weight | 6.53kg |
| Peripheral | WLAN | IEEE 802.11ax |
| Peripheral | Bluetooth | Bluetooth® 5.3 |
| Environment | Operating Temperature | 0 ~ 40 °C (32 ~ 104 °F) |
| Environment | Operating Humidity | 10 ~ 95% @ 40°C non-condensing |
| Environment | Vibration | 0.5G |
| Environment | Shock | 10G peak acceleration (11 msec. duration) |
| Environment | System Protection | IP65 front panel |
| Environment | Certification | CE, FCC, CB, UL, CCC, BSMI |
| Power | Input Rating | 20V/4.5A (90W) |
| OS Support | OS Support | Win 10 IoT Enterprise 64bit/ Linux |
| Power Supply | DC Input Rating | 20V/4.5A (90W) |
| Power Supply | PoE | n/a |
| Power Supply | Power consumption | 54.2W |
| LCD Display | Size/Type | 23.8" FHD |
| LCD Display | Max.Resolution | 1920 x 1080 |
| LCD Display | Max. Color | 16.7M |
| LCD Display | Pixel Pitch (um) | 2745 x 2745mm |
| LCD Display | Brightness (cd/m2 ) | 350 |
| LCD Display | View Angle | 178° /178° |
| TPM | TPM | TPM 2.0 |
Advantech UTC-124I1 23.8" Ubiquitous Touch Computer with 11th Gen Intel® Core™ i5-1145G7E / i3-1115G4E Processor
