Advantech UTC-124G3 23.8" All-in-One Touch Computer with Intel® Celeron® J3455 Processor

Slimmer and lighter design

Low power and fanless system design

Built-in Intel® Celeron® J3455 processor

23.8" monitor with 16:9 widescreen display

IP65-rated front panel for water and dust resistance

Clean back cover design with 3 Way IO cable routing

Supports both landscape and portrait screen orientations

VESA 100 mm standard mounting holes for varied mounting demands

Support DeviceOn/iService software for remote device management

		UTC-124G3P-ATS0E
Color	Color	Silver
Display	Size	23.8" TFT LCD
Display	Max. Resolution	FHD (1920 x 1080)
Display	Brightness	350 cd/m²
Touch Screen	Type	Projected Capacitive
Processor System	CPU	Intel® Celeron® J3455
Processor System	RAM	4GB DDR3L
Processor System	Storage	1 x M.2 2242 SSD / 1 x 2.5 internal SATA storage
Processor System	OS	Win 10 IoT Enterprise 64bit / Android 10.1 / Linux Ubuntu 20.04
I/O Interface	Serial Port	1 x COM (RS-232) ; 1 x COM (RS-232/422/485)
I/O Interface	USB Port	2 x USB2.0, 4 x USB3.0
I/O Interface	Ethernet	2 x Gigabit Ethernet ports
I/O Interface	Output	1 x HDMI
I/O Interface	Audio	1 x Line-out, 1 x Mic-in
I/O Interface	Cash Drawer	1 x RJ11
I/O Interface	Speaker	2 x 2W Speaker
I/O Interface	Extendable Slot	1 x M.2 2230 E-Key, 1 x Full-size Mini-PCIe for mSATA SSD
Peripheral	WLAN	N/A
Peripheral	Bluetooth	N/A
Environment	Operating Temperature	0 ~ 40 °C (32 ~ 104 °F)
Environment	Operating Humidity	10 ~ 95% @ 40°C non-condensing
Environment	Vibration	0.5G
Environment	Shock	10G peak acceleration (11 msec. duration)
Environment	System Protection	IP65 front panel
Power	Input Rating	12-24 V/7-3.5 A (90W Adapter)
