| UTC-320KP-ATB0E | UTC-320KP-ATB1E | ||
| Color | Color | Black | Black |
| Display | Size | 21.5" TFT LCD | 21.5" TFT LCD |
| Display | Max. Resolution | FHD (1920 x 1080) | FHD (1920 x 1080) |
| Display | Brightness | 250 cd/m² | 250 cd/m² |
| Touch Screen | Type | Projected Capacitive | Projected Capacitive |
| Processor System | CPU | Intel® Atom® N97 | Intel® Atom® i3-N305 |
| Processor System | RAM | 8GB DDR5 | 8GB DDR5 |
| Processor System | Storage | 1 x 2.5 internal SATA HDD bay | 1 x 2.5 internal SATA HDD bay |
| I/O Interface | Serial Port | 1 x RS-232 (RJ-48) ; 1 x RS-232/422/485 (RJ-48) | 1 x RS-232 (RJ-48) ; 1 x RS-232/422/485 (RJ-48) |
| I/O Interface | USB Port | 1 x USB Type C DC IN, 1 x USB Type C, 2 x USB 3.2, 2 x USB 2.0 Type A | 1 x USB Type C DC IN, 1 x USB Type C, 2 x USB 3.2, 2 x USB 2.0 Type A |
| I/O Interface | Ethernet | 2 x Gigabit Ethernet (RJ-45) | 2 x Gigabit Ethernet (RJ-45) |
| I/O Interface | Output | 1 x HDMI | 1 x HDMI |
| I/O Interface | Audio | 1 x 3.5mm Universal Audio Jack | 1 x 3.5mm Universal Audio Jack |
| I/O Interface | Speaker | 2 x 2W Speaker | 2 x 2W Speaker |
| I/O Interface | Extendable Slot | 1 x M.2 2280/2242 M-Key for NVMe(PCIe Gen3) / SATA SSD 1 x M.2 2230 E-Key | 1 x M.2 2280/2242 M-Key for NVMe(PCIe Gen3) / SATA SSD 1 x M.2 2230 E-Key |
| Environment | Operating Temperature | 0~40° C | 0~40° C |
| Environment | Operating Humidity | 10 ~ 95% @ 40°C non-condensing | 10 ~ 95% @ 40°C non-condensing |
| Environment | System Protection | IP65/ NEMA4 Compliant front panel | IP65/ NEMA4 Compliant front panel |
| Environment | Vibration | 0.5G | 0.5G |
| Environment | Shock | 10G peak acceleration (11 msec. duration) | 10G peak acceleration (11 msec. duration) |
| Power | Input Rating | 20V/4.5A (90W) | 20V/4.5A (90W) |
| OS Support | OS Support | Win 10/11 IoT Enterprise 64bit/ Linux / Android 14 | Win 10/11 IoT Enterprise 64bit/ Linux / Android 14 |
Advantech UTC-320K 21.5" Ubiquitous Touch Computer with Intel® Atom N97/ Core™ i3-N305 processors
