Advantech UTC-520G 21.5" Ubiquitous Touch Computer with Intel® Pentium® N4200 processor

Low power consumption and fanless design

Built in Intel® Pentium® N4200 processor

21.5" monitor with 16:9 widescreen display

IP65-rated front panel for water and dust resistance

All in one aluminum extrusion design

Supports both landscape and portrait screen orientations

VESA 100 mm standard mounting holes for varied mounting demands

White RAL9016 Available

Equipped with DeviceOn/iService software for remote device management

		UTC-520G-PE	UTC-520GP-ATB0E
Display	Brightness	250 cd/m² (optional 400 nits)	Black
Display	Size	21.5" TFT LCD
Display	Max. Resolution	FHD (1920 x 1080)
Display	Brightness	250 cd/m² (optional 400 nits)
Touch Screen	Type	Projected Capacitive
Processor System	CPU	Intel® Pentium® N4200
Processor System	RAM	1 x SO-DIMM DDR3L 1866 MHz up to 8GB
Processor System	Storage	1 x 2.5 internal SATA HDD bay
Processor System	OS	Win 10 IoT Enterprise / Android 6.0 / Linux Ubuntu 17.04
I/O Interface	Serial Port	2 x COM (RS-232)
I/O Interface	USB Port	2 x USB2.0, 2 x USB3.0
I/O Interface	Ethernet	2 x Gigabit Ethernet (RJ-45)
I/O Interface	Output	1 x VGA port, 1 x HDMI port
I/O Interface	Audio	1 x Line-out, 1 x Mic-in
I/O Interface	Extendable Slot	Full-size Mini PCIe / M.2
Power	Input Rating	12 V/5 A (60 W ITE Adapter)
Environment	System Protection	IP65 front panel
Environment	Operating Temperature	0~40° C
Environment	Operating Humidity	10 ~ 95% @ 40°C non-condensing
Environment	Vibration	0.5G
Environment	Shock	5G peak acceleration (11 msec. duration)
Environment	Certification	CE (RED Compliance), FCC, CB, UL, CCC,BSMI
