| UTC-542IP-ATB0E | ||
| Display | Size | 42.5" TFT LCD |
| Display | Max. Resolution | FHD (1920 x 1080) |
| Display | Brightness | 450 cd/m² |
| Touch Screen | Type | Projected Capacitive Touch Panel (Pcap. Flat Glass) |
| Processor System | CPU | Intel® Core™ i5-1145G7E |
| Processor System | RAM | 8G DDR4 |
| Processor System | Storage | 1 x 2.5 internal SATA HDD bay |
| Processor System | OS | Win 10 IoT Enterprise, Win 11 IoT Enterprise, Android 14, Ubuntu 22.04 |
| I/O Interface | Ethernet | 2 x Gigabit Ethernet (RJ-45) |
| I/O Interface | USB Port | 4 x USB 3.2, 1 x USB Type C |
| I/O Interface | Output | 1 x HDMI / 1 x DP |
| I/O Interface | Audio | 1 x Line-out, 1 x Mic-in |
| I/O Interface | Speaker | 2 x 10W Speaker |
| I/O Interface | Extendable Slot | 1 x M.2 E-Key 2230 (PCIe x 1, USB2.0, I2C), 1 x M.2 B-Key 3042 (USB2.0) w/ Nano-SIM, 1 x M.2 M-Key 2280 (PCIe x4 Gen.4 for PCIe SSD), optional SATA |
| Power | Input Rating | 24 V / 9.59 A (230W ITE adapter) |
| Environment | Operating Temperature | 0 ~ 40 °C (32 ~ 104 °F) |
| Environment | System Protection | IP65 front panel |
| Environment | Operating Humidity | 10 ~ 95% @ 40°C non-condensing |
| Environment | Vibration | 0.5G |
| Environment | Shock | 5G peak acceleration (11 msec. duration) |
Advantech UTC-542I 42.5" Ubiquitous Touch Computer with 11th Gen Intel® Core™ i7/i5/i3 Processor
