| UTC-520FT-ATB0E | ||
| Display | Size | 21.5" TFT LCD |
| Display | Max. Resolution | FHD (1920 x 1080) |
| Display | Brightness | 250 cd/m² (optional 500/1200 nits) |
| Touch Screen | Type | Projected Capacitive. Glass Panel (7H Hardness) |
| Touch Screen | Cover Glass Surface Treatment | Optional (AR / AG / Vandal Proof) |
| Display | Camera | Optional built-in camera |
| Display | Light Sensor | Optional light sensor w/ LED indicator |
| Processor System | CPU | Intel® Core™ i5-6300U |
| Processor System | RAM | 64G SSD |
| Processor System | Storage | 1 x 2.5 internal SATA HDD bay |
| Processor System | OS | Win 10 IoT Enterprise 64bit / Android 6.0 / Linux Ubuntu 18.04 |
| I/O Interface | Serial Port | 2 x COM (RS-232, M12 waterproof connector) |
| I/O Interface | USB Port | 2 x USB 2.0 (M12 waterproof connector),1 x USB 3.0 (M12 waterproof connector) |
| I/O Interface | Ethernet | 2 x Gigabit Ethernet (RJ-45, supports Wake on LAN, M12 waterproof connector) |
| I/O Interface | Extendable Slot | 1 x Full-size Mini PCIe, 1 x M.2 |
| Environment | Operating Temperature | -10 ~ 50 °C |
| Environment | Operating Humidity | 10 ~ 95% @ 40°C non-condensing |
| Environment | System Protection | IP66/69K full system |
| Environment | Vibration | 0.5G |
| Environment | Shock | 5G peak acceleration (11 msec. duration) |
| Power | Input Rating | 24V/5A |
Advantech UTC-520FT 21.5" Ubiquitous Touch Computer (IP66&69K) with Intel® Core™ i5-6300U
